電阻抗量測量儀器
| 一．導電地板的必要性: |
| 靜電發生的根源，如產業機械、空調、人體等皆是。生產機械等人體以外的物體在事先都可以接地線以預防靜電的發生，惟人體在室內走動時雖然不是固定的靜電發生源，但仍能持靜電不少。由於人體經常接觸地床，地床與鞋間的摩擦難免發生靜電，故導電地床是為人體的帶電速離而設，藉以防止靜電發生的必要措施。 |
| 一．NEEDFUL REASON FOR CONDUCTIVE FLOOR |
| ORIGIN OF STATIC ELECTRICITY CAN BE FROM PRODUCING MACHINES , AIR CONDITIONING , HUMAN BODY AND SO ON , NON-HUMAN BODY SUCH AS PRODUCING MACHINES CAN BE GROUNDED , HUMAN BODYS MOVING AROUND ROOMS , BECAME ORIGIN ALSO ITSELF IS ELECTRIFIED STATIC ELECTRICITY DCCURS BY FRICTION BETWEEN HUMAN BODY AND FLOOR , BECAUSE. HUMAN BODY ALWAYS TOUCHING TO FLOOR , CONDUCTIVE FLOORS IS APPLIED IN ORDER TO LEAK ELECTRIFICATION RIGHT AWAY AND IS NEEDFUL TO PREVENT FROM ELECTRICITY DISORDER. |
| 二．特徵 |
| 708-S-EC 防止靜電地板是把導電材料加入無溶劑的環氧樹脂，塗抹在水泥素地上達到防止靜電效果的工法，自平表面平坦適合於無塵室，無接縫、耐衝擊、耐重壓、耐磨損，以及耐藥品性。 |
| 二．CHARACTERISTICS |
| 708-S-EC ANTI-STATIC FLOOR COARING IS PAINTED ON THE CONCRETE BACKING WITH CONDUCTANCE MATERIAL AND SOLVENTLESS EPOXY RESIN , ITS SURFACE IS SMOONTH, SEAMLESS SUITABLE FOR CLEAN ROOM, ANTI-IMPACT、UNTI-HEAVY PRESSURE、WEAR PROOF、 AND EXCELLENT CHEMICAL RESISTANCE。 |
| 三．主要用途： |
| 無塵室、電子公司、製藥廠、計算機房、印刷廠、油墨廠、食品廠、半導體廠、倉庫等。 |
| 三．MAIN FUCTION: |
| IT CAN BE USED IN ELECTR ON COMPANY、PHARMACEUTICAL PLANT、COMPUTER ROOM、PRINTING FACTORY、INK MANUFACTORY、FOOD FACTORY、 SEMICONDUCTOR MANUFACTORY、AND WARE HOUSE ETC。 |
| 四．電阻量測之基本規則 |
| 根據美國防火協會指定NFPA-99 之方法或ANSI/ESD-S7.1 方法測試 1. 點對點之表面電阻抗值平均 1.0 X 10000至5.0X1000000Ω 2. 點至接地點之表面電阻值2.5X104以上 |
| 四．RESISTANCE TESTING FUNDAMENTALS |
| RESISTANCE IS TO BE MEASURED AS SPECIFIED BY NFPA-99A QUIDE LINES OR ANSI/ESD-STANDARD 7.1 1.POINT-TO-POINT RESISTANCE MEASUREMENT MUST HAVE AN ELECTRICAL RESISTANCE OF 1.0 X 10000 至 5.0 X 1000000Ω 2. RESISTANCE TO QROUDABLE POINT MEASUREMENT MUST HAVE AN ELECTRICAL RESISTANCE OF 2.5 X 10000 UP |
